Creabest LiFePO4 120Ah 12.8V Deep Cycle Battery for RV Marine Leisure Boat Caravan Camping Storage Power
Creabest RV Battery(LiFePO4) – Several advantages
Our LiFePO4 battery pack is inner BMS (battery manag-ement system) control. Thus, if the battery works over specified, BMS will stop the battery pack working. Whatever over-charge or over-discharge, over temperature or over voltage, BMS will cut it off. The battery will not work any longer. Our LiFePO4 battery pack is the most ideal battery for you.
Improvement in safety
Light Weight
Excellent performances at high temperature
Much long cycle life
Higher energy density than Lead-Acid
No memory effect,More environmental
Product Specifications(VB005 Series)
| Voltage | 12.8V | Cell Type | LiFePO4 |
| Capacity | 120Ah | Discharge Temperature | -20°C -60°C |
| Total Energy | 1535Wh | Charge Temperature | 0°C -55°C |
| Standard discharge current | 100A | Storage Temperature | -20°C -60°C |
| Max discharge current | 150A | Terminal Type | M8 |
| Standard Charge Curren | 30A-60A | Communication | N/A |
| Recommended charge Voltage | 14.4V-14.6V | Communication Terminal | N/A |
| BMS low voltage protection | 8V | Net Weight | 20KG |
| Series/Parallel | 4S1P | Dimensions | 356x170x232mm |
| Resistance | ≤10mΩ | Inverter | 12V 2000W |
Creabest LiFePO4 Batttery Widely Used In
Creabest LiFePO4 battery, specifically a lithium-ion battery, which uses LiFePO4 as a cathode material, and a graphitic carbon electrode with a metallic current collector grid as the anode.Because of the outstanding advantages in safety and cycle life, LiFe-PO4 battery iswidely used in power storage and vehicle.
【APPLICATION in Modification & Aftermarket】
1). The volume of LiFePO4 battery with the same specification and capacity is 2/3 of the volume of lead-acid battery, and the weight is 1/3 that of lead-acid battery.
2). Charge faster. Support high power charger charging.
3). Wide range of applications: campers, caravans, camping, boat, outdoor lighting, outdoor tools, car start temporarily, Off-grid, and so on.
【QUALITY VERIFIED】
This battery has been tested in several conditions, and the testing results are great.
* The LiFePO4 battery did not give rise to burning or exploding when being punctured in the nail penetration test.
* Its Cold Cranking Amps and voltage were all performing normal, even in the low temperature test.
* The great stability in high temperature was remarkable.
* Equiped with first-rate BMS, the battery went well in the short-circuit test, discharge test and the charge test as well.
【Attention】
Warranty: 2 years comes with unlimited technical support for the life of the battery
